American scooter Honda Elite 2010

2010 Honda Elite

American Honda is proud to announce the latest early introduction of another 2010-model-year machine, the Elite scooter.

Modern, sporty styling, comfortable seating with two-up capacity and strong, responsive performance in a sleek and highly economical scooter are the hallmarks of the new 2010 Elite. This stylish new scooter has it all. Featuring a new 108cc liquid-cooled, fuel-injected four-stroke engine and a light-handling chassis, the new Elite provides all the comfort and quality of a Honda in an affordable around-town runabout that anybody can enjoy. Quick trips to the store and other errands are the Elite’s specialty, thanks to a generous under-seat storage area that’s big enough to stow a full-face helmet and more.

Honda SH150i 153cc

2010 Honda SH150i - USA Specifications
MSRP: $4499 USD

ENGINE
Model: SH150i
Engine Type: 153cc liquid-cooled single-cylinder four-stroke
Bore and Stroke: 58mm x 57.8mm
Compression ratio: 11.0:1
Valve Train: SOHC; two-valve
Induction: PGM-FI with automatic enrichment
Ignition: Digital with electronic advance
Transmission: Honda V-Matic belt-converter automatic transmission

Suspension
Front: 33mm hydraulic fork; 3.5 inches travel
Rear: Swingarm with dual hydraulic shocks, spring preload adjustability; 3.3 inches travel

Brakes
Front: Single 220mm disc with two-piston caliper
Rear: Drum with CBS

Tires
Front: 100/80-16
Rear: 120/80-16
Wheelbase: 53.4 inches
Seat Height: 30.9 inches
Fuel Capacity: 1.8 gallons, including
0.5-gallon reserve
Colors: Red, Black
Curb Weight*: 302 pounds
*Includes all standard equipment, required fluids and full tank of fuel-ready to ride.
Meets current EPA standards

SH150i scooter Engine

Features/Benefits
Features
o Large 16-inch 100/80 front tire and 16-inch 120/80 rear tire provide a great ride.
o Long comfortable seat offers excellent rider and passenger accommodations.
o 1.8-gallon fuel tank offers ample cruising range.
o Instrumentation includes an analog speedometer, odometer, fuel, clock and coolant temperature gauge.
o Maintenance-free battery.
o Ignition switch/steering lock helps provide security when parked.
o Stylish rear carrier.
o Transferable one-year, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
o Enhance your Honda ownership experience and visit HRCA.Honda.com.

Engine/Drivetrain
o Liquid-cooled fuel-injected four-stroke 153cc single-cylinder engine features a single overhead camshaft with peppy engine performance, excellent fuel economy and clean, efficient operation.
o Programmed Fuel Injection (PGM-FI) for excellent throttle response over a wide range of riding conditions.
o Sophisticated Honda V-Matic automatic transmission provides seamless acceleration throughout a wide range of speeds along with twist-and-go simplicity.
o Maintenance-free digital ignition.
o Exhaust catalyzer and advanced digital mapping reduce emissions.

Chassis/Suspension
o 33mm hydraulic front fork with 3.5 inches of travel provides a plush and responsive ride.
o Dual rear shocks have 3.3 inches of travel and spring preload adjustability for a smooth, comfortable ride.
o Combined Braking System (CBS) with a 220mm front disc brake with hydraulic two-piston caliper plus a rear drum brake offers excellent stopping power.

Honda SH150i

2010 Honda SH150i

When it's time for fun in the sun, no other machine outshines the sleek Honda SH150i scooter. And you don't have to take our word for that; a real crowd favorite among scooter riders in Europe, the stylish SH150i now makes its way to the shores of the USA where it's destined to become an instant favorite for economical and fun transportation. This fashion-conscious scooter delivers a smart blend of Euro style and low maintenance, plus easy-to-use controls including the simplicity of twist-and-go operation with the power for two-up riding. Without a doubt, the Honda SH150i is the coolest way to get around on a warm summer's day!

Following the successful public unveiling of the 2010 Fury, American Honda is proud to announce the early introduction of another exciting 2010-model-year machine, the SH150i scooter.

The SH150i now makes its way to the shores of the United States where it is destined to become an instant favorite. The stylish SH150i delivers an exceptional blend of new, modern styling, easy operation, plus economical and fun transportation. A responsive 153cc liquid-cooled single-cylinder four-stroke engine with fuel injection delivers smooth acceleration and the power for two-up riding, while 16-inch wheels provide great handling and a reassuring ride. The SH150i also offers the stopping power of Honda's Combined Brake System, plus useful amenities such as an under-seat storage area and the option of an accessory rear box that's both fashionable and functional.

Honda makes this impressive combination of utility and style available in the SH150i for an affordable suggested retail price of $4499. The first units will begin arriving in dealership showrooms in May of 2009, and will be available in Red and Black colors.

Liquid Cooled Kymco Downtown 300i 2011

2011 Kymco Downtown 300i - Specifications
American MSRP: $5,599 USD
Canadian MSRP: $5,995 CDN

Engine Type Liquid Cooled, Single cylinder, 4 Stroke
Displacement 298.9 cc
Bore & stroke 72.7 x 72 mm
Compression ratio 10.8 :1
Valve train O.H.C., Chain Drive
Fuel Delivery Electronic Fuel Injection
Ignition Electronic Fuel Injection
Transmission Automatic CVT
Spark plug CR7E (NGK)
Emission CEPA Environmental Registered
Fuel capacity 12.5 litres
Tires 120/80-14 Front; 150/70-13 Rear
Front Suspension Telescopic Forks
Rear Suspension Swing Arm
Front Brakes Disk
Rear Brakes Disk
Instrument cluster Analog Speedometer & Tachometer, Digital Odometer, Digital Clock, Low Fuel Indicator, Light Indicator, Digital Coolant Temperature Light, Maintenance Light, Oil Pressure Light, Low Battery Light
Stands Centre and Side Stand
Storage compartment Under Seat Compartment for two full faced helmets
Complete Size (L x W x H) 2200 x 810 x 1150 mm
Seat Height 775 mm
Dry weight 166.5 kg
Maximum Passengers 2
Warranty Two Year Limited Warranty

The electronic fuel injection Downtown 300i is Scooter family

The Downtown 300i was designed and built for an enjoyable commute! With the open road performance of a maxi scooter and sport bike agility, the Downtown 300i delivers the ultimate scooter riding experience. This new entry in the KYMCO scooter family is powered by an all new 4-valve Electronic Fuel Injected engine coupled to an agile, responsive, light weight dual cradle steel chassis. The onboard carrying capacity of the Downtown 300i offers all the space for your daily commuting needs with a lighted, under seat storage space big enough for two helmets and a watertight console compartment for cell phone storage equipped with a 12V accessory outlet right at your fingertips. Add an optional top case and your daily commuter ride turns into a weekend touring machine

Additional Features: Modern colour schemes, electronic fuel injection, front and rear disk brakes, integrated passenger grips, center hook, illuminated under seat storage with room for 2 helmets, watertight in dash storage compartment with 12v accessory outlet for cell phones, digital instrument cluster, windscreen, dual beam quartz halogen head lights, integrated passenger pegs, 5 position adjustable rear shocks, 5 in 1 magnetic key lock system, sturdy center stand, spring assisted side stand, 12.5 litre fuel capacity.

You’re about to enjoy commuting like never before. The Downtown 300i was designed and built for it!

With the open road performance of a maxi scooter and sport bike agility, the Downtown 300i delivers the ultimate scooter riding experience. This new entry in the KYMCO Scooter family is powered by an all new 4-valve Electronic Fuel Injected engine coupled to an agile, responsive, light weight dual cradle steel chassis. The onboard carrying capacity of the Downtown 300i offers all the space you need. A lighted, underseat storage space is big enough for two helmets and a watertight console compartment for cell phone storage, equipped with a 12V accessory outlet for charging your phone, is right at your fingertips, satisfying all your daily commuting needs. Add an optional top case and your daily commuter ride turns into a weekend touring machine. The Downtown 300i: class leading performance and styling plus great fuel economy too! Choose from three elegant color options: Pearl White, Silver or Burnt Orange. Get Ready to Be Amazed!

the KYMCO Xciting 500Ri ABS Scootermatic

the Xciting 500Ri ABS is truly a state of the art product design from KYMCO. You'll never have to sacrifice comfort again with a fully automatic transmission, adjustable back rest, 4 position brake levers, and a smooth ride! Be sure to take a closer look for chrome finishing, red accents, texturized black satin side panels, and even a carpet-lined under seat storage compartment.

Additional Features: Dual front disks with dual piston calipers, ABS, single piston floating rear caliper, low center of gravity, adjustable rear struts, elegant 3 pod instrument cluster, adjustable brake levers, modern 2 tone colour scheme, adjustable backrest, sporty black satin rear view mirrors, sleek design, side stand with integrated engine kill switch, sturdy center stand, hand parking brake, textured black satin side panels, under seat storage with 12v outlet, light and cell phone holder, folding aluminum passenger pegs, 12.8 liter fuel capacity.

The new Xciting 500Ri delivers KYMCO quality and economy in an agressive sport styling. Its 500cc, electronic fuel injected, DOHC liquid-cooled engine delivers at highway speeds with plenty of passing power. KYMCO's popular CVT transmission provides stepless acceleration from a standing start all the way up to cruising speed. The 15" front and 14" rear tires, adjustable hydraulic rear shocks and telescopic front forks smooth out the bumps. A well-padded driver's seat (30.25" seat height) with adjustable backrest, four- position adjustable brake levers, and the aerodynamic, sport style windscreen all add up to an incredibly comfortable and safe ride.

Xciting 500 Ri ABS

2011 Kymco Xciting 500 Ri ABS - Specifications
American MSRP: $6,299 USD
Canadian MSRP: $7,495 CDN

Engine Type Liquid Cooled, Single Cylinder, 4 Stroke
Displacement 498 cc
Bore & stroke 92 x 75mm
Compression ratio 10.5: 1
Valve train D.O.H.C., Chain Drive
Fuel Delivery Electronic Fuel Injection
Ignition Electronic Fuel injection
Transmission Automatic CVT
Spark plug NGK CR8E
Emission CEPA Environmental Registered
Fuel capacity 12.8 litres
Tires 120/70-15 Front; 150/70-14 Rear
Front Suspension Telescopic Forks
Rear Suspension Adjustable Hydraulic Shocks
Maximum Weight Capacity 150 kg
Front Brakes Dual Vented Disks / Dual Piston Caliper / ABS
Rear Brakes Single Vented Disk/ Dual Piston Caliper
Instrument Cluster Analog Speedometer, Tachometer, Digital Odometer, Digital Clock, Gas Gauge, Light Indicator, Coolant Temperature Light, Maintenance Light, Oil Pressure Light, Low Battery Light, Parking Brake Light
Stands Centre and Side Stand
Storage compartment Under Seat Compartment, Front Glove Box and Integrated Seat Cubby
Complete Size (L x W x H) 2255 x 810 x 1450 mm
Seat Height 765 mm
Dry weight 200 kg
Maximum Passengers 2
Warranty Two year limited warranty

All color options Vespa LX 50-4V

the Vespa LX 50 is more than 60 years in the making. Witness the evolution of style, comfort, and performance with the core values of Vespa that never change: eco-friendly engineering, passion, individualism and integrity.
Max. Speed: 39 mph Gas Mileage: 85-90 mpg
MSRP: Please call or email for latest prices.
Color Options: Celeste Blue, Midnight Blue, Dragon Red, Montebianco White, Espresso Bronze, Daring Plum

LX 50 4 Stroke / 4 Valve Take a new spin on an original classic. The LX 50 features an automatic twist-and-go transmission, steel body, and electric starter. A low center of gravity and larger front wheel provides control and agility, and an ergonomicallydesigned seat allows for a comfortable ride. Brake with confidence, with the LX’s advanced mixed-type braking system. The 4 valve engine has more power and improved fuel efficiency.

four-stroke catalytic Hi-PER4 The Vespa LX50 4V

This Specifications of Vespa LX50 4V
2010 MSRP: $3,299 USD

ENGINE TYPE Single cylinder, four-stroke catalytic Hi-PER4
CYLINDER CAPACITY 49.4cc
BORE x STROKE 39 mm x 41.8 mm
MAX POWER AT SHAFT 3.2 kW at 8,250 rpm
MAX TORQUE 3.5 Nm at 6,500 rpm
MAX SPEED 39 mph (63 km/h)
FUEL / TANK CAPACITY Unleaded 2.3 gallons (8.6 litres)
GAS MILEAGE 95-100 mpg
DISTRIBUTION Cam head single shaft-SOHC (2 valves)
COOLING SYSTEM Ram air with sound proof cover
LUBRICATION Wet sump, 850cc capacity; chain-driven lobe pump; intake and delivery filters
INGINTION Electric and kick start
GEARS CVT (Continuous Variable Transmission) transformer with torque slave
CLUTCH Automatic dry centrifuge with damper buffers
CHASSIS Load-bearing steel chassis with welded structural supports
FRONT SUSPENSION Single arm with helical spring and dual effect hydraulic single shock absorber
REAR SUSPENSION Coil spring and dual effect single shock absorber
FRONT BREAK 200 mm ø steel disc with hydraulic command
REAR BREAK 110 mm ø drum with mechanical command
FRONT TIRE Tubeless 110/70-11"
REAR TIRE Tubeless 120/70-10"
LENGTH 69.1" (1755 mm)
WIDTH 29.1" (740 mm)
WHEELBASE 50.4" (1280 mm)
SEAT HEIGHT 30.5" (775 mm)
DRY WEIGHT 225 lbs (102 kg)
TYPE APPROVAL EPA and CARB
AVAILABLE COLORS Dragon Red, Midnight Blue, Sky Blue, Bronze/Espresso, Dragon Red, Pink

The LX50 4V Sky Blue

2010 The New Vespa LX50 4V

From the same pedigree as the first Vespa prototype built by Piaggio in 1946, the 2010 Vespa LX50 is more than 60 years in the making. Witness the evolution of style, comfort and performance with the core values of Vespa that never change: eco-friendly engineering, passion, individualism and integrity.

LX 50 4 Stroke / 4 Valve Take a new spin on an original classic. The LX 50 features an automatic twist-and-go transmission, steel body, and electric starter. A low center of gravity and larger front wheel provides control and agility, and an ergonomicallydesigned seat allows for a comfortable ride. Brake with confidence, with the LX’s advanced mixed-type braking system. The 4 valve engine has more power and improved fuel efficiency.
